Lightweight Collaborative Robot Parameters
|
effective load
|
3kg-10kg
|
|
Effective working radius
|
600mm-1300mm
|
|
freedom degree
|
6
|
|
Protection level
|
IP54
|
|
noise
|
≤68dB
|
|
Installation direction
|
Any direction
|
|
Minimum detectable collision force
|
5N
|
|
Prolong the response time after collision
|
≤0.1s
|
|
Human – computer interaction
|
12 – inch teaching pendant or
mobile terminal APP.P
|
|
Repeatability
|
±0.02mm
|
|
Absolute positioning accuracy
|
0.7mm
|
|
Range of joint motion
|
±360°
|
|
Maximum joint speed
|
±180°/s
|
|
Maximum speed of the tool end
|
2m/s
|
|
Base diameter
|
122mm
|
|
Total weight of the whole machine
|
13kg
|
|
Working temperature
|
-10℃～ 60℃（No condensation）
|
|
Working humidity
|
25~85% (No condensation)
|
|
Equipment and materials
|
Aluminum alloy, ABS indicators
|
